Clipping PathsDrawingPipelineTGA

Reads image in JPEG format, converts clipping path to alpha channel and saves to TARGA 32 format.

Code Snippet

using (var reader = ImageReader.Create("Apple.jpg"))
using (var alpha = new Bitmap(reader.Width, reader.Height, PixelFormat.Format8bppGrayscale, RgbColor.Black))
using (var writer = ImageWriter.Create("ConvertClippingPathToTga.tga"))
{
    using (var graphics = alpha.GetGraphics())
    {
        var path = reader.ClippingPaths[0];
        using (var graphicsPath = Path.Create(path, alpha.Width, alpha.Height))
        {
            graphics.FillPath(new SolidBrush(RgbColor.White), graphicsPath);
        }
    }

    using (var setAlpha = new Aurigma.GraphicsMill.Transforms.SetAlpha(alpha))
    {
        Pipeline.Run(reader + setAlpha + writer);
    }
}

Input

Output

Used APIs

• Aurigma.GraphicsMill.Bitmap.GetGraphics
• Aurigma.GraphicsMill.Codecs.ImageReader
• Aurigma.GraphicsMill.Codecs.ImageReader.ClippingPaths
• Aurigma.GraphicsMill.Codecs.ImageReader.Create(String)
• Aurigma.GraphicsMill.Codecs.ImageWriter
• Aurigma.GraphicsMill.Codecs.ImageWriter.Create(String)
• Aurigma.GraphicsMill.Drawing.Graphics.FillPath(Brush,Path)
• Aurigma.GraphicsMill.Drawing.Path
• Aurigma.GraphicsMill.Drawing.Path.Create(Path,Int32,Int32)
• Aurigma.GraphicsMill.Drawing.SolidBrush
• Aurigma.GraphicsMill.Transforms.SetAlpha
