Draw text watermark on thumbnail image

View as Markdown

PipelineResizeTextThumbnail

This sample shows how to create a thumbnail image and draw a semi-transparent text watermark on top of it using the GraphicsMill transforms and advanced drawing APIs. It demonstrates how to resize the source image with the Resize transform, register a custom font, and render text with Drawer and PlainText. You can read more information about drawing in the documentation.

Code Snippet

// Read the source image and prepare pipeline elements.
using (var reader = ImageReader.Create("Venice.jpg"))
using (var resize = new Resize(500, 500, ResizeInterpolationMode.Anisotropic9, ResizeMode.Fit))
using (var drawer = new Drawer())
using (var writer = new JpegWriter("TextWatermark.jpg"))
using (var fr = new CustomFontRegistry())
{
    // Add font to the custom font registry and get its PostScript name.
    var psName = fr.Add("Jost-Regular.ttf")[0].PostscriptName;

    // Configure the Drawer to render the watermark text.
    drawer.Draw += (sender, e) =>
    {
        // Set the custom font registry to the current graphics context.
        e.Graphics.FontRegistry = fr;

        // Create the font to be used for the watermark text.
        var font = e.Graphics.CreateFont(psName, 50);

        // Create the  text object with semi-transparent white brush.
        var text = new PlainText("WATERMARK TEXT", font)
        {
            Brush = new SolidBrush(RgbColor.White.ScaleAlpha(0.7f)),
            Alignment = TextAlignment.Left,
        };

        // Place the text with a small margin from the left/bottom edges.
        var margin = 10;

        text.Position = new System.Drawing.PointF(margin, e.Height - margin);

        // Draw the watermark text onto the image.
        e.Graphics.DrawText(text);
    };

    // Run the pipeline.
    Pipeline.Run(reader + resize + drawer + writer);
}

Input



Output



Used APIs
