Autorotate

Rotate EXIF Bitmap Transform

Automatically rotates image based on EXIF orientation metadata.

Сode Snippet

public static void Run()
{
    Autorotate("Gondola.jpg", "Autorotate.jpg");
}

private static bool Autorotate(string pathIn, string pathOut)
{
    ushort orientation;

    using (var reader = ImageReader.Create(pathIn))
    {
        var exif = reader.Exif;

        if (exif == null || !exif.Contains(ExifDictionary.Orientation))
        {
            return false;
        }

        orientation = (ushort)exif[ExifDictionary.Orientation];

        // 1         2       3      4         5            6           7          8

        // ######  ######      ##  ##      ##########  ##                  ##  ##########
        // ##          ##      ##  ##      ##  ##      ##  ##          ##  ##      ##  ##
        // ####      ####    ####  ####    ##          ##########  ##########          ##
        // ##          ##      ##  ##
        // ##          ##  ######  ######

        if (orientation == 1)
        {
            return false;
        }

        using (var writer = ImageWriter.Create(pathOut))
        {
            if (!(reader is JpegReader) || !(writer is JpegWriter))
            {
                RotateWithRecompression(reader, writer, orientation);

                return true;
            }
        }
    }

    RotateJpegWithRecompression(pathIn, pathOut, orientation);

    return true;
}

private static void RotateWithRecompression(ImageReader reader, ImageWriter writer, uint orientation)
{
    using (var rotate = new Aurigma.GraphicsMill.Transforms.Rotate())
    using (var flip = new Aurigma.GraphicsMill.Transforms.Flip())
    {
        flip.Type = Aurigma.GraphicsMill.Transforms.FlipType.None;

        switch (orientation)
        {
            case 2:
                flip.Type = Aurigma.GraphicsMill.Transforms.FlipType.Vertical;
                break;

            case 3:
                rotate.Angle = 180f;
                break;

            case 4:
                flip.Type = Aurigma.GraphicsMill.Transforms.FlipType.Vertical;
                rotate.Angle = 180f;
                break;

            case 5:
                flip.Type = Aurigma.GraphicsMill.Transforms.FlipType.Horizontal;
                rotate.Angle = 270f;
                break;

            case 6:
                rotate.Angle = 90f;
                break;

            case 7:
                flip.Type = Aurigma.GraphicsMill.Transforms.FlipType.Horizontal;
                rotate.Angle = 90f;
                break;

            case 8:
                rotate.Angle = 270;
                break;
        }

        var jpegWriter = writer as JpegWriter;

        if (jpegWriter != null)
        {
            jpegWriter.Quality = 85;
        }

        var metadataWriter = writer as IMetadataWriter;

        if (metadataWriter != null)
        {
            metadataWriter.Exif = reader.Exif ?? new ExifDictionary();
            metadataWriter.Exif[ExifDictionary.Orientation] = 1;

            metadataWriter.Iptc = reader.Iptc;
            metadataWriter.AdobeResources = reader.AdobeResources;
            metadataWriter.Xmp = reader.Xmp;
        }

        if (flip.Type == Aurigma.GraphicsMill.Transforms.FlipType.None)
        {
            Aurigma.GraphicsMill.Pipeline.Run(reader + rotate + writer);
        }
        else if (rotate.Angle == 0)
        {
            Aurigma.GraphicsMill.Pipeline.Run(reader + flip + writer);
        }
        else
        {
            Aurigma.GraphicsMill.Pipeline.Run(reader + rotate + flip + writer);
        }
    }
}

private static void RotateJpegWithRecompression(string pathIn, string pathOut, uint orientation)
{
    using (var losslessJpeg = new LosslessJpeg(pathIn))
    {
        System.Drawing.RotateFlipType flipType;

        switch (orientation)
        {
            case 2:
                flipType = System.Drawing.RotateFlipType.RotateNoneFlipX;
                break;

            case 3:
                flipType = System.Drawing.RotateFlipType.Rotate180FlipNone;
                break;

            case 4:
                flipType = System.Drawing.RotateFlipType.Rotate180FlipX;
                break;

            case 5:
                flipType = System.Drawing.RotateFlipType.Rotate90FlipX;
                break;

            case 6:
                flipType = System.Drawing.RotateFlipType.Rotate90FlipNone;
                break;

            case 7:
                flipType = System.Drawing.RotateFlipType.Rotate270FlipX;
                break;

            case 8:
                flipType = System.Drawing.RotateFlipType.Rotate270FlipNone;
                break;

            default:
                flipType = System.Drawing.RotateFlipType.RotateNoneFlipNone;
                break;
        }

        losslessJpeg.Exif[ExifDictionary.Orientation] = 1;

        losslessJpeg.WriteRotated(pathOut, flipType);
    }
}

Input

Output
